JTAG Verification IP

Truechip's JTAG Verification IP provides an effective & efficient way to verify the components interfacing with the JTAG interface of an ASIC/FPGA or SoC.​

Truechip's JTAG VIP is fully compliant with Standard JTAG Version IEEE 1149.1-2013 JTAG specification from JEDEC. This VIP is lightweight with an easy plug-and-play interface so that there is no hit on the design time and the simulation time.

Key Benefits

• Available in native SystemVerilog (UVM/OVM/VMM) and Verilog
• Unique development methodology to ensure the highest level of quality.
• Availability of Compliance & Regression Test Suites.
• 24X5 customer support
• Unique and customizable licensing models
• Exhaustive set of assertions and cover points with connectivity example for all the components.
• Consistency of interface, installation, operation, and documentation across all over.

Features

• Supports IEEE 1149.1-2013 JTAG Protocol Standard.
• DUT can be:
  • Master
  • Slave
• Configurable instruction register.
• Configurable data register width.
• Dynamically configurable data register width.
• User-defined instructions.
• User-defined data registers.
• Reports current state of TAP finite state machine.
• Support for both public and private instructions.
• User-defined BFM instructions.
• Support for all Test Access Port (TAP) pins.
• Internal and external clock and reset modes.
• Supports constraints randomization.
• Status counters for various events on the bus.
• Supports callbacks for a user to define a custom instruction decoder.
• Supports callbacks for a user to get a callback on each state of the TAP controller.
• Support all types of timing and protocol violation detection.
• Functional coverage for checking all possible stimulus checking.
• Protocol-aware debug.

Deliverables

• JTAG Driver BFM/Agent
• JTAG Monitor & Scoreboard
• JTAG Controller BFM/Agent
• Test-Bench Configurations
• Test Suite (Available in Source code)
  • Basic Protocol Tests
  • Directed & Random Tests
  • Assertions & Cover Point Tests
• Integration Guide, User Manual, and Release Notes
